Thông tin chi tiết sản phẩm:
Thanh toán:
|
| Tải tối đa: | 5KN, 1 tấn, 2 tấn | Lực chính xác: | ≤0,5% |
|---|---|---|---|
| Độ phân giải dịch chuyển: | 1/1000 | chiều rộng thử nghiệm: | 380mm |
| Cung cấp điện: | 220v | Trọng lượng máy: | 250kg |
| Kích thước máy: | 80*55*220cm | Phạm vi tốc độ: | 0,01-500mm/phút hoặc 1000mm/phút |
| Chiều rộng thử nghiệm hiệu quả: | 390mm | đột quỵ kéo: | 800mm;1000mm;1200mm |
| Tốc độ kiểm tra: | 0,001~200 mm/phút; 500mm/phút (tùy chọn 1000mm/phút) | độ chính xác dịch chuyển: | ±0,5%/±0,2% |
| phạm vi biến dạng: | Khoảng cách tối thiểu: 10mm, Phạm vi tối đa: 800mm | Quyền lực: | 0,4kW |
| Đơn vị: | Kg, N, LB, TẤN | ||
| Làm nổi bật: | 5KN Max Load Universal Testing Machine,0.5% Accuracy Tensile Testing Machine,380mm Testing Width Hounsfield Testing Machine |
||
| Model | ZL-8001 |
|---|---|
| Max load | 5KN,10KN, 20KN |
| Accurate grade | 1 % /0.5 % |
| Effective measuring range | 0.2%~100%(1grade)/0.4%~100%(0.5 grade) |
| Measuring accuracy | Display the value ±1%/Display the value±0.5% |
| Tester resolution | Max load 1/200000, regardless of inside and outside, constant the resolution |
| Load sensor | Basic configuration: sensor(max load): one. Extended configuration: can add more sensors |
| Effective testing width | 390mm (can be widened according to customer's requirement) |
| Effective Tensile stroke | 800mm;1000mm;1200mm (can be increased the height according to customer's requirement) |
| Range of testing speed | 0.001~200mm/min; 500mm/min (1000mm/min is option) |
| Accuracy of displacement measurement | Tolerance: ±0.5%/ tolerance: ±0.2% |
| Deformation of measured system | Min span: 10mm, Max range of deformation: 800mm. Extended deformation: Min span: 25mm,50mm,100mm, range of deformation: 5mm,10mm,25mm |
| Accuracy of measured deformation | Tolerance: ±0.5% (according to requirement of customer to choose the larger or small deformation) |
| Safety | Electronic-limit protection |
| Testing platform moving device | Fast/slow two speeds to control, can jog |
| Return back | Manual or automatic operation. After the test, the moving iron returns to initial position with the highest speed by manual or automatic operation |
| Overload protection | Overload 10%, automatic protection |
| Fixture | A set of tensile fixture |
| Machine size | 80x55x220cm (length*width*height) |
| Power system | Panasonic AC Servo Motor + Driver + high-precision ball screw |
| Power supply | 220V, 50HZ |
| Power | 0.4KW (depending on different demand of force, using different motor) |
| Machine weight | (about) 250 Kg |
| Units | Kg, N, LB, TON, can be exchanged |
